TELEHOUSE SHANGHAI ZhangJiang
TELEHOUSE SHANGHAI ZhangJiang Data Center*, in conjunction with a local IDC,ISP provider, provides unrivaled customer support and service.
*TELEHOUSE SHANGHAI ZhangJiang is actually operated by a Chinese local IDC, ISP operator, strictly based on TELEHOUSE Global Standards.
- Access
The Data Center, located in the eastern part of Shanghai, boasts a modern and fully developed infrastructure, providing customers with:
- Convenient and Quick Access
TELEHOUSE is located between the Shanghai Pudong International Airport and Lujiazui. From either point, you can reach the Data Center in 30 minutes by car.
- Convenient and Quick Access
- High-Tech Infrastructure
- TELEHOUSE SHANGHAI ZhangJiang is located in a High-Tech Park which is managed by the Shanghai government.
- The power supply of TELEHOUSE SHANGHAI ZhangJiang is from 2 different power stations and the quake proof of building is the top level in Shanghai.
Specifications
| Building | Location | Zhangjiang Hi-tech Park |
|---|---|---|
| Provided Area | 1,600m² | |
| Ceiling Height | 4.5m (Slab) | |
| Raised Floor Height | 750mm | |
| Maximum Floor Load | 800 kg/㎡ | |
| Fire Extinguisher | IG541 gas extinguishing system VESDA sensor | |
| Power Supply | Building Power Receiving |
Dual feeds of power supply from 2 different substation with 2 routes |
| Emergency Generator | N + 1 | |
| UPS | 2（N+1) | |
| Power / Rack | 1.8-3.0kVA (Over 3kVA needs consulting in advance) | |
| Climate Control | CRAC Config | N + 1 |
| Temp & Humidity | Temp : 22 ±2℃ Humidity : 55% ± 10% |
|
| Leak Sensor | Yes | |
| Feeder Type | Dual | PDU：A+B UPS：2(N+1) |
| Network | Transport Carrier | CT, CU, Fiberlink, SDS |
| ISP | SDS | |
| In-house Cabling | Yes | |
| O&M | Operation Hour | 24/7 |
| Security | 24/7 CCTV, IC card, metal sensor Security Guard | |
| Others | Rest Space | Yes |
| BCP Solution | Yes | Parking Space | In place |
Connectivity
- China Telecom(CT)
- China Unicom(CU)
- Fibrlink
- SDS
